Capacitors — Manufactured by Samsung Electro-Mechanics
This 3.3nF MLCC is a high-performance surface-mount capacitor utilizing the stable X7R dielectric, which offers predictable capacitance changes over temperature. Housed in a compact 0402 (1005 metric) package and rated for 50V, it provides a reliable solution for high-density circuit designs. The component features a nickel barrier termination to ensure excellent solderability and resistance to leaching during assembly. Its primary advantage is the balance of stability and volumetric efficiency in general-purpose electronic applications.
3.3nF 50V X7R ±10% 0402 Multilayer Ceramic Capacitors MLCC – SMD/SMT ROHS
📦 0402
⚙️ X7R Multilayer Ceramic Capacitor (MLCC)
🌿 RoHS Compliant
⚙️ X7R Multilayer Ceramic Capacitor (MLCC)
🌿 RoHS Compliant
- Max Voltage (Vmax): 50V
- Operating Temperature: -55°C to +125°C
Starting at
$0.0030667
✨ Key Features
Compact 0402 SMD footprint; Temperature-stable X7R dielectric (Class II); 50V DC rated voltage; ±10% capacitance tolerance; Nickel (Ni) barrier with Tin (Sn) plating for superior solderability; Fully RoHS and REACH compliant.
🎯 Applications
Decoupling and bypass in digital logic circuits; Filtering in power management modules; Noise suppression in telecommunications equipment; General-purpose timing and coupling; Consumer electronics and industrial controls.
⚡ Electrical Characteristics
Capacitance: 3.3nF; Capacitance Tolerance: ±10% (K code); Dissipation Factor (DF): 2.5% max at 1kHz; Insulation Resistance (IR): 10 GΩ or 500/C MΩ (whichever is smaller); Aging Characteristic: Typical for Class II dielectrics.
⚠️ Absolute Maximum Ratings
Maximum Operating Temperature: +125°C; Minimum Operating Temperature: -55°C; Rated DC Voltage (VDC): 50V; Dielectric Withstanding Voltage: 250% of rated voltage for 5 seconds.
🔌 Pinout & Connection Diagram
2-Terminal SMD Package; Non-polar device; Terminal 1: Termination/Electrode; Terminal 2: Termination/Electrode.
🔄 Equivalent & Alternative Components
- Murata GRM155R71H332KA01D
- TDK C1005X7R1H332K
- KEMET C0402C332K5RACTU
- Taiyo Yuden UMK105BJ332KV-F
