1604 Datasheet: 50V 2.2nF Capacitor – FH (Guangdong Fenghua)
Capacitors — Manufactured by FH(Guangdong Fenghua Advanced Tech)
This is a 2.2nF multilayer ceramic capacitor (MLCC) with a 50V rating and X7R temperature characteristic, housed in a compact 0603 SMD package. Designed for high reliability in both analog and digital circuits, it offers stable capacitance across its full operating temperature range. The monolithic laminated structure ensures excellent mechanical strength and robust electrical performance. It is particularly effective in high-voltage DC applications and power conversion circuits due to its specialized design and soldering versatility. This component provides a balance between high volumetric efficiency and stable performance under varying thermal conditions.
2.2nF 50V X7R ±10% 0603 Multilayer Ceramic Capacitors MLCC – SMD/SMT ROHS
📦 0603
⚙️ MLCC X7R
🌿 RoHS Compliant
⚙️ MLCC X7R
🌿 RoHS Compliant
- Max Voltage (Vmax): 50V
- Operating Temperature: -55°C to +125°C
Starting at
$0.0027259
✨ Key Features
Specialized high-voltage reliability design; Monolithic laminated structure for enhanced reliability; Excellent soldering ability and resistance to soldering heat; Compatible with both reflow and wave soldering processes; High and stable capacitance performance across specifications.
🎯 Applications
Analog and digital modems, LAN/WAN interfaces, lighting ballast circuits, voltage multipliers, DC-DC converters, and back-lighting inverters.
⚡ Electrical Characteristics
Capacitance: 2.2nF; Tolerance: ±10%; Dielectric: X7R; Rated Voltage: 50V; Operating Temperature: -55°C to +125°C; Capacitance change with temperature: ±15%.
⚠️ Absolute Maximum Ratings
Maximum Rated Voltage (Vmax): 50V DC; Operating Temperature Range: -55°C to +125°C; Storage Temperature Range: -55°C to +125°C.
🔌 Pinout & Connection Diagram
Standard 0603 SMD mechanical structure consisting of two metallic terminals. This component is non-polarized and can be mounted in either orientation.
🔄 Equivalent & Alternative Components
- Murata GRM188R71H222KA01D
- TDK C1608X7R1H222K080AA
- Samsung CL10B222KB8NNNC
- KEMET C0603C222K5RACTU
❓ Frequently Asked Questions
What are the advantages of the X7R dielectric used in this MLCC?
X7R is a temperature-stable dielectric, meaning its capacitance change is limited to ±15% over the temperature range of -55°C to +125°C, making it suitable for bypass and decoupling applications where stability is required.
Can this capacitor be used in both reflow and wave soldering?
Yes, according to the manufacturer’s specification, it has excellent soldering resistance and is suitable for both reflow and wave soldering methods.
Is this component polarized?
No, multilayer ceramic capacitors (MLCCs) are non-polarized components and do not have a positive or negative terminal.
